Inno3d Nvidia GeForce RTX 2060 Super Twin X2 OC RGB 8GB GDDR6 Graphics Card
8GB GDDR6 Video Memory
256-bit Memory Bus
PCI-Express 3.0 x16 Interface
1 x 8 Pin Power Connectors
14 Gbps Memory Speed
Bus Support PCI-E 3.0 X16
Video Memory 8GB GDDR6
CUDA Cores 2176
GPU Boost Clock 1665 MHz
Memory Bus 256-bit
TECHNICAL SPECIFICATIONS
GPU Engine Specs_
CUDA Cores_ 2176
Boost Clock (MHz)_ 1665
Base Clock(MHz)_ 1470
Thermal and Power Spec_
Minimum System Power Requirement (W)_ 550
Supplementary Power Connectors_ 8-pin
Memory Specs_
Memory Clock_ 14Gbps
Standard Memory Config_ 8GB
Memory Interface_ GDDR6
Memory Interface Width_ 256-bit
Memory Bandwidth (GB/sec)_ 448
Feature Support_
Real-Time Ray Tracing_ Yes
Ray Tracing Cores_ Yes
Tensor Cores_ Yes
NVIDIA Architecture_ Turing
Microsoft DirectX_ 12 Ultimate
NVIDIA DLSS_ Yes
NVIDIA GeForce Experience_ Yes
NVIDIA Ansel_ Yes
NVIDIA FreeStyle_ Yes
Bus Support_ PCI-E 3.0 X16
NVIDIA ShadowPlay_ Yes
NVIDIA Highlights_ Yes
OS Certification_ Windows 10, Linux, FreeBSDx86
NVIDIA G-SYNC-Ready_ Yes
Game Ready Drivers_ Yes
NVIDIA Studio Drivers_ Yes
NVIDIA GPU Boost_ Yes
Vulkan API_ Yes
OpenGL_ 4.5
DisplayPort 1.4a_ Yes
NVIDIA Encoder_ 6th Generation
NVIDIA Decoder_ 4th Generation
Display Support_
Multi-Monitor_ Yes
Maximum Digital Resolution_ 76804320
HDCP_ 2.2
Standard Display Connectors_ HDMI 2.0b, 3x DisplayPort 1.4
Graphics Card Dimensions_
Length_ 220mm
Height_ 113mm
Width_ 2-slot
Specification: Inno3d Nvidia GeForce RTX 2060 Super Twin X2 OC RGB 8GB GDDR6 Graphics Card
Brand_
INNO3D
CHIPSET_
NVIDIA
BIT RATE_
256
CAPACITY_
8 GB
FANS_
2
MEMORY TYPE_
GDDR6
PROCESSOR SERIES_
RTX
WARRANTY_
3 Years Warranty
Product Type_
Graphics Card
FORM FACTOR_
ATX , E-ATX , MICRO-ATX
