MSI MEG CORELIQUID S360 Liquid CPU Cooler
AIO Liquid Cooler
Tripple PMW fans
360mm Aluminium Radiator
SATA Power Connector
50,000 Hours Fan life
Cooler Type Liquid Cooler (AIO)
Radiator Size 360mm
Number of Fans 3
Fan Connector PWM (4-pin)
Fan Power Consumption 4.8w (Max)
OVERVIEW
MSI MAG CORELIQUID S360 Liquid CPU Cooler is a top-of-the-line liquid cooling system for the CPU. The product is designed to be compatible with all current Intel and AMD sockets, including the AM5. It has a 360mm radiator and is designed to be easy to install. The MAG CORELIQUID S360 is also easy to clean, as it has a large fill port and a transparent design.
The water block of MAG CORELIQUID S360 Liquid Cooler Water Block has a 60mm fan which helps to dissipate heat for M.2 SSD, CPU VRM, and surrounding components.
The pump of this MSI cooler is integrated with the radiator to reduce the noise and reduce the noise. In connection, placing the pump on the radiator increases the life of the pump by removing it from the heat source and It provides out-of-the-box support for the LGA 1700 socket.
This MSI liquid cooler has a split path through the radiator that dissipates heat rapidly, returning to the cold liquid loop.
Made with three layers of netted plastic tubing and a strong mesh, this MSI MAG cooler is designed for stylish but flexible. It is designed with a secure installation bundle compatible with several Intel and AMD motherboards.
TECHNICAL SPECIFICATIONS
Intel Socket Support_LGA 1700, 1200, 1151, 115, 1155, 1156, 2066, 2011-3, 2011
AMD Socket Support_AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1, TR4, sTRX4, SP3
Water Cooling Tube Length_400 mm
Water Cooling Tube Material_Black Rubber + Mesh
Radiator Material_Aluminum
Radiator Dimensions (W x D x H)_394 x 120 x 27 mm / 15.5 x 4.7 x 1.06 inches
Radiator Size_360 mm
Number of Fans_3
Fan Speed_0 ~ 2000 RPM
Fan Power Consumption_4.8 W (MAX)
Fan Rated Current_0.4 A (MAX)
Fan Bearing_Hydro-Dynamic Bearing
Fan Static Pressure_2.21 mm H2O
Fan Noise Level_22.7 dBA
Fan Air Flow_56.2 CFM
PWM Mode_Yes
Cable Length (PWM Cable)_350 mm / 13.78 inches
Fan Life Expectancy_50,000 Hours
Fan Connector_4 pin PWM
Pump Rated Current_0.33A
Pump Speed_2800 +/-300 RPM (PWM controlled)
Pump Power Consumption_4W
Pump Noise Level_21.2 dBA
Pump Life Expectancy_50,000 Hours
Pump Connector_4 pin PWM
Cold Plate Material_Copper
Panel Type_IPS
Panel Size_2.4 inch
Panel Color Depth_16 bits
Panel Brightness_500 nits
Interface Connector_USB 2.0 pin header
Panel Resolution_320 x 240
Power Connector_SATA
Block Dimensions (W x D x H)_95 x 95 x 83.53 mm
Fan Dimensions (W x D x H)_120 x 120 x 25 mm, 4.7 x 4.7 x 0.98 inches
Specification: MSI MEG CORELIQUID S360 Liquid CPU Cooler
Brand
MSI
Product Type
CPU Coolers
COLOR
BLACK
COOLER TYPE
LIQUID AIO COOLER
FAN SIZE
360 mm
LIGHTING
NONE
FAN CONTROLLER
YES
IDEAL FOR GAMING
YES
WARRANTY
3 Years Warranty
